osl-eln-demo
OSL ELN Demo
Iterative Agent Demo Visualization - See how the iterative agent builds a knowledge graph from natural language experiment descriptions.
Prerequisites
Follow https://github.com/LLM4ELN/llm4eln-assessment to set up the project, virtual environment and llm provider (step 1-3).
Make sure to install the additional packages opensemantic.lab and "git+https://github.com/OpenSemanticLab/osw-python", overall
uv add langchain langchain-openai langchain-ollama langchain-anthropic langchain-google-genai langchain-ollama python-dotenv opensemantic.lab "git+https://github.com/OpenSemanticLab/osw-python"
or use
uv sync
OSL Login
Go to https://llm4eln.semos.dev and login via ORCID
Optional: Go to Preferences and set your Real Name (otherwise only your ORCID ID will be shown)
Got to https://llm4eln.semos.dev/wiki/Special:BotPasswords and create a bot password. Grant “edit existing pages”, “create, edit and move pages”, “upload new files”, “upload, replace and move files” and “delete pages, revisions and log entries” permissions.
.env File
Create a .env file in the project root based on the .env.example file and fill in your credentials.
# Azure OpenAI
API_PROVIDER=azure
API_KEY=<your-api-key>
API_ENDPOINT=https://your-deplyoment.openai.azure.com/ # example
API_VERSION=2024-10-21 # example
API_MODEL=gpt-5-nano-2025-08-07 # example
OSW_USER=<user-id>@<bot-name>
OSW_PASSWORD=<bot-password>
Run the Demo
Basic Example
Construct a LaboratoryProcess entry based on a natural language description.
python demo_basic.py
You should not see any error in the console. A link should be logged that points to the generated entry in the demo instance - open it in your browser to validate the results.
Data Model Suggestion Example
Lookup or suggest a data model based on a natural language description.
python schema_catalog.py
Iterative Agent Example
Run an agent that iteratively creates a LaboratoryProcess entry and linked entities (people, organizations, etc.) based on a natural language description.
python demo_iterative_agent.py
Concept
Simple iterative approach
define the tool create_linked_entity with the following steps:
- Lookup a schema that matches the user request
- Prompt the LLM to fill the schema properties while
- ask for special treatment of properties with
rangeannotation by re-entering (via recursive tool call) at step 1 for each such property - ask to skip calling
create_linked_entityif the request is already stored in the global log in order to prevent endless loops (e.g. if Person -hasOrganization-> Organization -hasMember-> Person)
- ask for special treatment of properties with
- Compare the created entity with existing entities by using RAG + LLM judging. If a match is found, return the existing entity ID
- Else return the created entity ID to be stored in the parent object
Challenges / Limitations
Despite prompt engineering efforts, LLMs still struggle with certain aspects of the task:
- LLMs often try complete all properties of a schema even if no information is provided, e.g.
deepseek-v3.2creates keywords like “Keyword for Example Lab” when no keywords are provided in the description. - Since properties with
rangeannotation are of typestringin the JSON-SCHEMA representation of OSL schemas, LLMs sometimes try to fill them with textual descriptions instead of looking up / creating the linked entity. - Placing step 4. directly after step 1 using the textual description instead of the already created JSON representation does not work well with some LLMs due to missing data normalization. E.g.
deepseek-v3.2struggle to compare dates in different formats (e.g. “01.01.2025” vs “2025-01-01”) - using the ISO format (JSON-SCHEMA formatdate) on both sides helps here. - Some LLMs have limitations regarding tool use (e.g. only tool use OR structured output) or JSON schema features (e.g. no nested objects).
Evaluation
The following models were evaluated for the simple iterative approach:
| Provider | Model | Result |
|---|---|---|
| azure | gpt-5-nano-2025-08-07 | ✅ Basic works, interactive works |
| azure | gpt-5-mini-2025-08-07 | ✅ Basic works, interactive works |
| azure-foundry-anthropic | claude-sonnet-4-5 | ✅ Basic works, interactive works |
| azure-foundry-anthropic | claude-haiku-4-5 | ✅ Basic works, interactive works |
| azure-foundry | deepseek-v3.2-speciale | ❌ Error: too many requests |
| azure-foundry | deepseek-v3.2 | ⚠️ Basic works, iterative not: cannot compare ISO dates correctly (works with structured data compare) |
| azure-foundry | cohere-command-a | ⚠️ Basic works, iterative not: cannot compare ISO dates correctly |
| azure-foundry | deepseek-r1-0528 | ⚠️ Basic works, iterative partially, struggles with tool calling |
| azure-foundry | mistral-large-3 | ❌ Error: invalid input |
| azure-foundry | llama-3.3-70b-instruct | ⚠️ Basic works, interactive not: model doesn’t support more than one tool call |
| azure-foundry | llama-4-maverick-17b-128e-instruct-fp8 | ⚠️ Basic works, interactive not: states entities are equal when they are not |
| azure-foundry | gpt-oss-120b | ❌ Error: tool_choice ‘required’ not supported |
| azure-foundry | kimi-k2-thinking | ✅ Basic works, interactive works |
| azure-foundry | phi-4-reasoning | ❌ Error: JSON schema contains unsupported xgrammar features |
| vllm | microsoft/Phi-4-reasoning | ⚠️ Basic works, interactive not: model refuses tool calling |
| vllm | microsoft/Phi-4-mini-instruct | ⚠️ Basic works, interactive not: model refuses tool calling |
| vllm | microsoft/Phi-4-mini-reasoning | ⚠️ Basic works, interactive not: model refuses tool calling |
Advanced approach
- lookup the schema that matches the request
- Compare the request with previous requests stored in a global log via LLM judging. If a match is found, return the corresponding entity ID
- Else prompt a LLM to provide a list of properties that can actually be filled based on the user request
- remove all other properties from the schema
- use the modified schema to prompt a LLM to create the entity via structured output, handling properties with
rangeannotation as strings containing the descriptions of the linked entities - for each property with
rangeannotation re-enter at step 1 with the description provided in step 4 to lookup / create the linked entity and the annotations of the corresponding property. Replace the textual description with the found / created entity ID. - Compare the created entity with existing entities by using RAG + LLM judging. If a match is found, return the existing entity ID
- Store the created entity and return its ID
